Fixed Flange with Schluter®-KERDI: Pre-pitched channel with set length with center outlet location.
FCSIG 65 FEATURES
- Fixed Flange: Pre-pitched channel with set length with center outlet location
- Factory applied Schluter° Kerdi Membrane
- 16 gauge, 304L stainless steel perforated grate with stainless steel channel
- Finished width: 2-9/16", Min. height above subfloor*: 1-1/16"
- Capacity: 9 gallons per minute
- No-hub connection to waste line with rubber coupling (not included)
- Recess channel into subfloor with placement brackets ST 65
- Metal edge detail available ME 96
Standard Finishes Available
- Satin Stainless - SS
- Polished Stainless - PS
- Matte Black - BK
- Satin Bronze - SB
- Oil Rubbed Bronze – ORB
Specialty Finishes Available
- 3 to 4 week lead time
- Include: Matte White, Gunmetal, Satin Champagne, Polished Gold, and Polished Brass. (in order of the images)
COMPLETE KITS
- FCSIG 6524: (1) 24" grate and 24" stainless steel channel
- FCSIG 6532: (1) 32" grate and 32" stainless steel channel
- FCSIG 6536: (1) 36" grate and 36" stainless steel channel
- FCSIG 6542: (1) 42" grate and 42" stainless steel channel
- FCSIG 6548: (1) 48" grate and 48" stainless steel channel
- FCSIG 6560: (1) 60" grate and 60" stainless steel channel
